Type SC3 Hydro-lock Sleeve


Product Description
Type SC3 hydro-lock sleeve is designed for interchangeable tool assembly, which promotes easy switch between tools.
Max. Operation Speed: 9000 rpm.
Highlight Features
- Easy and quick pressurization with an Allen T wrench;
- We offer a comprehensive range of products to match most grips in the market;
- With accessories, multiple tools can be assembled and used at the same time.
Download: SuperSource Type SC3 Hydro-lock Sleeve
Category: Hydro-lock Sleeves
SKU | Product | D | D1 | D2 | D4 | D5 | D6 | D7 | D9 | L | L1 | L2 | H | N |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
G012 05420 | SC3 40/60 x 96-7 | 40 | 60 | 120 | 75 | 14 | 9 | 100 | 63 | 96 | 68 | 11 | 6 | |
G012 05520 | SC3 40/60 x 96-7 | 40 | 60 | 120 | 75 | 14 | 9 | 100 | 63 | 96 | 68 | 11 | 6 | |
Please note that all the dimensions in the above table are in metric (mm). |
