Spiral Insert Cutterhead
Product Description
Our Spiral Insert Cutterhead is a high-performance tool designed for planers, jointers, and CNC machines, featuring a helical arrangement of indexable tungsten carbide inserts for smooth finishes, reduced tear-out, and quieter operation. Optimized for efficiency and durability, it is suitable for a wide range of materials—including solid wood, MDF, plywood, and melamine panels.
Maximum Operation Speed: 9000 rpm.
Knives inserts sold separately.
Highlight Features
- Helical Cutting Design: The spiral layout ensures continuous contact with the wood, delivering smoother finishes and minimizing tear-out—particularly effective on figured or irregular grain. The angled design also promotes efficient chip evacuation, reducing clogging and boosting cutting performance.
- Tungsten Carbide Inserts: Equipped with tungsten carbide inserts known for exceptional hardness and durability, this cutterhead outlasts traditional high-speed steel knives, reduces tooling costs, and eliminates the need for frequent sharpening.
- Quiet Operation: The segmented, shearing action of the spiral cutterhead produces significantly less noise than straight-knife alternatives, creating a quieter and more comfortable working environment.
- Anodic Oxidation Treated: Our cutterhead body features a high-hardness anodic oxidation treatment, offering superior wear resistance and increased screw retention. This advanced coating ensures lasting precision in insert placement and extends the cutterhead's service life compared to standard anodizing.
Download: Spiral Insert Cutterhead PDF
Category: Cutterheads
SKU | H901 |
Product Type | Spiral Insert Cutterhead |
Cutterhead Material | High-strength Aluminum Alloy |
Outer Diameter D | 90 - 200 mm |
Bore Diameter D1 | 19 - 100 mm |
Cutting Length L | 14 - 130 mm |
Cutting Angles | 15x15x2.5-30° or 14x14x2-30° |
Knife Pockets | 2, 4, 6, 8, 10, 12, 14, 16, 18, 20 |
